Quip MCP Server (TypeScript)

A Model Context Protocol (MCP) server for interacting with Quip spreadsheets, implemented in TypeScript. This server provides tools to read spreadsheet data from Quip documents and return the content in CSV format.

Features

Retrieve spreadsheet content from Quip documents
Support for selecting specific sheets by name
Returns data in CSV format with metadata
Handles authentication via Quip API token
Provides appropriate error messages for non-spreadsheet documents
Automatically handles large spreadsheets by truncating content when necessary
Stores spreadsheet content locally for efficient access
Multiple storage options including local filesystem and Amazon S3
Provides resource URIs for accessing complete spreadsheet content
Enhanced error handling with detailed error messages and proper error types
Mock mode for testing without a real Quip API token
Structured logging with different log levels (debug, info, warn, error)
API key authentication for securing the HTTP server
Caching mechanism for improved performance with frequently accessed resources
Health check endpoint for monitoring server status

Installation

Using npm

# Install globally
npm install -g @zxkane/quip-mcp-server

# Or install locally in your project
npm install @zxkane/quip-mcp-server

From Source

# Clone the repository
git clone https://github.com/zxkane/quip-mcp-server-typescript.git
cd quip-mcp-server-typescript

# Install dependencies
npm install

# Build the project
npm run build

Environment Variables

Create a .env file in the root directory with your Quip API token:

# Quip API token (required unless in mock mode)
QUIP_TOKEN=your_quip_api_token_here

# Quip API base URL (optional, defaults to https://platform.quip.com)
QUIP_BASE_URL=https://platform.quip.com

# Storage type (optional, defaults to 'local', can be 'local' or 's3')
# STORAGE_TYPE=local

# Storage path for CSV files (optional, defaults to ~/.quip-mcp-server/storage)
QUIP_STORAGE_PATH=/path/to/storage

# S3 storage configuration (required when STORAGE_TYPE=s3)
# S3_BUCKET=your-bucket-name
# S3_REGION=us-east-1
# S3_PREFIX=quip-data/
# S3_URL_EXPIRATION=3600

# MCP server port (optional, defaults to 3000)
MCP_PORT=3000

# Debug mode (optional, set to true to enable debug logging)
# QUIP_DEBUG=true

# Mock mode (optional, set to true to use mock data without a real Quip token)
# QUIP_MOCK=true

# JSON logging (optional, set to true to output logs as JSON)
# JSON_LOGS=true

# Authentication (optional, set to true to enable API key authentication)
# MCP_AUTH_ENABLED=true

# API key for authentication (optional, auto-generated if not provided)
# MCP_API_KEY=your_api_key_here

# API key header name (optional, defaults to X-API-Key)
# MCP_API_KEY_HEADER=X-API-Key

Usage

Running the Server

# Using npm with stdio transport (default)
npm start

# With command-line arguments
npm start -- --storage-path /path/to/storage --file-protocol --debug

# Using HTTP transport (set PORT and HOST environment variables)
PORT=3000 HOST=localhost npm start

# Using node directly
node dist/index.js --storage-path /path/to/storage

The server supports two transport protocols:

stdio transport (default): Used when running as a subprocess for tools like Claude.app
HTTP transport: Used when you want to expose the server over HTTP, which is useful for development or when running as a standalone service

To use HTTP transport, set the PORT environment variable (and optionally HOST).

For detailed information about transport options, configuration, security considerations, and environment-specific examples, see the Transport Documentation.

Transport Documentation

The Quip MCP server supports two transport types:

Stdio Transport: The default transport, used when running the server as a subprocess of another application (e.g., Claude.app).
HTTP Transport: Used when exposing the server over HTTP, allowing clients to connect over a network.

The detailed transport documentation covers:

Transport configuration options
Security considerations for each transport type
Environment-specific examples (local development, Claude.app integration, production deployment, Docker/container usage, CI/CD integration)
Troubleshooting common issues
Future considerations for transport improvements

Configure for Claude.app

Add to your Claude settings:

"mcpServers": {
  "quip": {
    "command": "node",
    "args": ["dist/index.js", "--storage-path", "/path/to/storage"],
    "env": {
      "QUIP_TOKEN": "your_quip_api_token"
    }
  }
}

If you want to use the file protocol for resource URIs:

"mcpServers": {
  "quip": {
    "command": "node",
    "args": ["dist/index.js", "--storage-path", "/path/to/storage", "--file-protocol"],
    "env": {
      "QUIP_TOKEN": "your_quip_api_token"
    }
  }
}

Command Line Arguments

The server supports the following command line arguments:

--storage-type <type>: Storage type (local or s3, defaults to 'local')
--storage-path <path>: Path to store CSV files (defaults to QUIP_STORAGE_PATH environment variable or ~/.quip-mcp-server/storage)
--file-protocol: Use file protocol for resource URIs (instead of quip:// protocol)
--s3-bucket <name>: S3 bucket name (required for S3 storage)
--s3-region <region>: S3 region (required for S3 storage)
--s3-prefix <prefix>: S3 prefix (optional for S3 storage)
--s3-url-expiration <seconds>: S3 URL expiration in seconds (default: 3600)
--use-presigned-urls: Generate presigned HTTPS URLs for S3 resources (instead of s3:// URIs)
--debug: Enable debug logging
--mock: Use mock mode (no real Quip token required)
--json: Output logs as JSON
--auth: Enable authentication
--api-key <key>: API key for authentication (auto-generated if not provided)
--api-key-header <header>: API key header name (defaults to X-API-Key)
--port <port>: HTTP port to listen on (defaults to MCP_PORT environment variable or 3000)

Example:

node dist/index.js --storage-path /path/to/storage --file-protocol --debug

Example with mock mode:

node dist/index.js --mock --storage-path /path/to/storage

Example with authentication:

node dist/index.js --auth --api-key your_api_key_here

Deploy to AWS Lambda + API Gateway

The Quip MCP server can be deployed to AWS Lambda with API Gateway to create a serverless, scalable HTTP endpoint. This setup is ideal for production environments and provides several benefits:

Serverless Operation: No need to manage servers
Auto-scaling: Handles varying loads automatically
High Availability: Distributed across multiple availability zones
Cost-effective: Pay only for what you use
Streamable HTTP Interface: Works with tools that support HTTP MCP servers

For detailed deployment instructions, see the Cloud Deployment section.

Available Tools

quip_read_spreadsheet

Retrieves the content of a Quip spreadsheet as CSV.

Parameters:

threadId (required): The Quip document thread ID
sheetName (optional): Name of the sheet to extract. If not provided, the first sheet will be used.

Example:

{
  "threadId": "AbCdEfGhIjKl",
  "sheetName": "Sheet1"
}

Response: The tool returns a JSON object containing:

csv_content: The spreadsheet content in CSV format (truncated if too large)
metadata: Additional information about the spreadsheet:
- total_rows: Total number of rows in the spreadsheet
- total_size: Total size of the CSV content in bytes
- is_truncated: Boolean indicating if the content was truncated
- resource_uri: URI to access the complete spreadsheet content

Example Response (default protocol):

{
  "csv_content": "header1,header2\nvalue1,value2\n...",
  "metadata": {
    "total_rows": 1000,
    "total_size": 52840,
    "is_truncated": true,
    "resource_uri": "quip://AbCdEfGhIjKl?sheet=Sheet1"
  }
}

Example Response (with --file-protocol):

{
  "csv_content": "header1,header2\nvalue1,value2\n...",
  "metadata": {
    "total_rows": 1000,
    "total_size": 52840,
    "is_truncated": true,
    "resource_uri": "file:///path/to/storage/AbCdEfGhIjKl-Sheet1.csv"
  }
}

Example Response (with S3 storage):

{
  "csv_content": "header1,header2\nvalue1,value2\n...",
  "metadata": {
    "total_rows": 1000,
    "total_size": 52840,
    "is_truncated": true,
    "resource_uri": "s3://my-bucket/quip-data/AbCdEfGhIjKl-Sheet1.csv"
  }
}

Example Response (with S3 storage and --use-presigned-urls):

{
  "csv_content": "header1,header2\nvalue1,value2\n...",
  "metadata": {
    "total_rows": 1000,
    "total_size": 52840,
    "is_truncated": true,
    "resource_uri": "https://my-bucket.s3.us-east-1.amazonaws.com/quip-data/AbCdEfGhIjKl-Sheet1.csv?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=..."
  }
}

Error Handling:

If the thread is not a spreadsheet, an error will be returned.
If the specified sheet is not found, an error will be returned.

Resource URIs

The server provides resource URIs for accessing complete spreadsheet content. These URIs can be used with the MCP resource access mechanism.

The server supports multiple URI formats depending on the configuration:

Default Protocol (quip://)

URI Format:

quip://{threadId}?sheet={sheetName}

Example:

quip://AbCdEfGhIjKl?sheet=Sheet1

File Protocol (with --file-protocol option)

URI Format:

file://{storage_path}/{threadId}-{sheetName}.csv

Example:

file:///home/user/.quip-mcp-server/storage/AbCdEfGhIjKl-Sheet1.csv

S3 Protocol (when using S3 storage)

URI Format:

s3://{bucket}/{prefix}/{threadId}-{sheetName}.csv

Example:

s3://my-bucket/quip-data/AbCdEfGhIjKl-Sheet1.csv

Presigned S3 URLs (when using S3 storage with USE_PRESIGNED_URLS=true)

URI Format:

s3+https://{bucket}/{prefix}/{threadId}-{sheetName}.csv

Which resolves to an HTTPS URL:

https://{bucket}.s3.{region}.amazonaws.com/{prefix}/{threadId}-{sheetName}.csv?{authentication_params}

Example:

https://my-bucket.s3.us-east-1.amazonaws.com/quip-data/AbCdEfGhIjKl-Sheet1.csv?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=...

When accessed, the resource returns the complete CSV content of the spreadsheet, regardless of size.

How It Works

The server uses two methods to extract spreadsheet data:

Primary Method: Exports the spreadsheet to XLSX format using the Quip API, then converts it to CSV.
Fallback Method: If the primary method fails, it parses the HTML content of the document to extract the table data.

For large spreadsheets, the server:

Saves the complete CSV content to local storage
Returns a truncated version (up to 10KB) with metadata
Provides a resource URI for accessing the complete content

Error Handling

The server implements a comprehensive error handling system with specific error types:

QuipMCPError: Base error class for all server errors
InvalidParamsError: For invalid request parameters
MethodNotFoundError: For unknown methods or tools
ParseError: For JSON parsing errors
AuthenticationError: For authentication failures
ResourceNotFoundError: For resource not found errors
QuipApiError: For Quip API errors
StorageError: For storage-related errors
TimeoutError: For request timeout errors

Each error type has a specific error code and can include additional data for debugging. This consistent error handling ensures that clients receive clear and actionable error messages, making it easier to diagnose and fix issues.

Mock Mode

The server includes a mock mode that doesn't require a real Quip API token. This is useful for testing and development. In mock mode, the server uses pre-defined sample data instead of making actual API calls to Quip.

To enable mock mode, use the --mock command line argument or set the QUIP_MOCK environment variable to true.

Mock mode provides several sample spreadsheets with different structures and sizes, allowing you to test your application's handling of various data formats without needing access to real Quip documents. This is particularly useful for development environments or CI/CD pipelines where you may not want to use real API credentials.

Structured Logging

The server implements structured logging with different log levels:

DEBUG: Detailed debugging information
INFO: General information about server operation
WARN: Warning messages
ERROR: Error messages

Logs can be output as plain text or JSON format. To enable JSON logging, use the --json command line argument or set the JSON_LOGS environment variable to true.

The structured logging system provides consistent log formatting and includes contextual information with each log entry, making it easier to filter and analyze logs. When JSON logging is enabled, logs can be easily parsed by log management systems for advanced monitoring and alerting.

Authentication

The server supports API key authentication for securing the HTTP server. When enabled, clients must include the API key in the request headers.

To enable authentication, use the --auth command line argument or set the MCP_AUTH_ENABLED environment variable to true. You can specify the API key using the --api-key argument or MCP_API_KEY environment variable. If not provided, a random API key will be generated and displayed in the logs.

The API key header name can be customized using the --api-key-header argument or MCP_API_KEY_HEADER environment variable. By default, the header name is X-API-Key.

Authentication is only applied to the HTTP transport mode and does not affect stdio transport, which is typically used in more controlled environments.

Caching

The server implements a caching mechanism for frequently accessed resources. This improves performance by reducing the number of disk reads and API calls.

Two types of caches are used:

csvCache: For caching CSV content (10 minutes TTL)
metadataCache: For caching metadata (30 minutes TTL)

The caching system automatically handles cache invalidation based on TTL (Time To Live) values and implements a simple LRU (Least Recently Used) strategy to prevent memory issues when dealing with many resources. This ensures optimal performance while maintaining reasonable memory usage.

Storage Options

The server supports two storage options:

Local Storage

By default, the server uses local file system storage to store CSV files. This is suitable for most use cases and provides good performance.

To configure local storage:

# Using environment variables
STORAGE_TYPE=local QUIP_STORAGE_PATH=/path/to/storage npm start

# Using command line arguments
npm start -- --storage-type local --storage-path /path/to/storage

S3 Storage

For production deployments or when you need to share data across multiple instances, you can use Amazon S3 storage. This allows you to store CSV files in an S3 bucket.

To configure S3 storage:

# Using environment variables
STORAGE_TYPE=s3 S3_BUCKET=your-bucket-name S3_REGION=us-east-1 npm start

# Using command line arguments
npm start -- --storage-type s3 --s3-bucket your-bucket-name --s3-region us-east-1

Additional S3 configuration options:

S3_PREFIX / --s3-prefix: Prefix for S3 object keys (e.g., "quip-data/")
S3_URL_EXPIRATION / --s3-url-expiration: URL expiration in seconds (default: 3600)
USE_PRESIGNED_URLS: Set to "true" to generate presigned HTTPS URLs for direct access to S3 resources

Presigned S3 URLs: When USE_PRESIGNED_URLS is set to "true", the server will generate presigned HTTPS URLs for resource URIs instead of s3:// URIs. This allows direct access to the resources without requiring AWS credentials or special S3 client libraries. Presigned URLs are temporary and expire after the time specified by S3_URL_EXPIRATION (default: 3600 seconds).

AWS Authentication: The S3 storage implementation uses the AWS SDK, which automatically loads credentials from the environment. You can provide AWS credentials using any of the standard methods:

Environment variables (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY)
Shared credentials file (~/.aws/credentials)
IAM roles for Amazon EC2 or ECS tasks

For more information on AWS authentication, see the AWS SDK documentation.

Health Check Endpoint

The server provides a health check endpoint at /health that can be used to monitor the server's status. This endpoint is available when running in HTTP transport mode.

To access the health check endpoint, send a GET request to /health:

curl http://localhost:3000/health

The endpoint returns a simple JSON response with status "ok" when the server is running properly:

{
  "status": "ok"
}

This endpoint can be used by monitoring tools or container orchestration systems to check if the server is healthy and ready to handle requests.

Cloud Deployment

AWS Lambda + API Gateway

The Quip MCP server can be deployed as a serverless application using AWS Lambda with API Gateway. This provides a scalable, low-maintenance deployment option with a streamable HTTP interface.

The project includes an AWS CDK infrastructure setup that automates the deployment of:

Lambda function with the Quip MCP server
API Gateway endpoint
S3 bucket for storing CSV files
Secrets Manager for storing sensitive information

For detailed deployment instructions, architecture overview, and usage information, see the AWS Lambda Deployment Guide in the infrastructure directory.

To connect Claude.app to your deployed MCP server, add the following to your Claude settings (after deployment):

"mcpServers": {
  "quip-remote": {
    "endpointUrl": "https://your-api-gateway-url/mcp",
    "headers": {
      "X-API-Key": "YOUR_API_KEY_VALUE"
    }
  }
}

Development

Project Structure

quip-mcp-server-typescript/
├── src/
│   ├── index.ts                 # Main entry point
│   ├── server.ts                # MCP server implementation
│   ├── cli.ts                   # Command-line argument handling
│   ├── quipClient.ts            # Quip API client
│   ├── mockClient.ts            # Mock Quip client for testing
│   ├── tools.ts                 # Tool definitions and handlers
│   ├── storage.ts               # Storage abstraction and implementations
│   ├── types.ts                 # TypeScript type definitions
│   ├── version.ts               # Version information
│   ├── errors.ts                # Error handling
│   ├── logger.ts                # Structured logging
│   ├── auth.ts                  # Authentication
│   └── cache.ts                 # Caching mechanism
├── tests/
│   ├── unit/                    # Unit tests
│   │   ├── server.test.ts
│   │   ├── quipClient.test.ts
│   │   ├── tools.test.ts
│   │   ├── storage.test.ts
│   │   └── ...
│   └── e2e/                     # End-to-end tests
├── infrastructure/              # AWS deployment resources
│   ├── cdk/                     # CDK project
│   │   ├── bin/
│   │   │   └── app.ts           # CDK app entry point
│   │   ├── lib/
│   │   │   └── quip-mcp-server-stack.ts  # Main CDK stack
│   │   ├── lambda/              # Lambda function code
│   │   │   ├── run.js           # Lambda handler
│   │   │   └── package.json
│   │   ├── package.json
│   │   └── tsconfig.json
│   └── README.md                # AWS deployment documentation
├── example-client/              # Example MCP client implementation
│   ├── src/
│   │   ├── client-common.ts
│   │   ├── http-client.ts
│   │   ├── stdio-client.ts
│   │   └── index.ts
│   ├── package.json
│   └── README.md
├── dist/                        # Compiled JavaScript output
├── .env.example                 # Example environment variables
├── .gitignore                   # Git ignore file
├── jest.config.js               # Jest configuration
├── tsconfig.json                # TypeScript configuration
├── package.json                 # npm package configuration
└── LICENSE                      # License file

Setting Up a Development Environment

# Clone the repository
git clone https://github.com/zxkane/quip-mcp-server-typescript.git
cd quip-mcp-server-typescript

# Install dependencies
npm install

# Build the project
npm run build

# Run in development mode
npm run dev

Scripts

npm run build: Build the project
npm start: Run the server
npm run dev: Run the server in development mode
npm test: Run tests
npm run test:watch: Run tests in watch mode
npm run test:coverage: Run tests with coverage
npm run test:e2e: Run end-to-end tests
npm run lint: Lint the code
npm run format: Format the code

Running Tests

# Run all tests
npm test

# Run tests with coverage
npm run test:coverage

# Run tests in watch mode
npm run test:watch

# Run end-to-end tests
npm run test:e2e

Debugging

You can use the MCP inspector to debug the server:

# Install the MCP inspector
npm install -g @modelcontextprotocol/inspector

# Debug the server
mcp-inspector node dist/index.js

Adding New Tools

To add new tools:

Define the tool in src/tools.ts by adding it to the getQuipTools() function:

export function getQuipTools(): Tool[] {
  return [
    {
      name: "quip_read_spreadsheet",
      description: "Read the content of a Quip spreadsheet...",
      inputSchema: {
        // Schema definition
      }
    },
    {
      name: "your_new_tool",
      description: "Description of your new tool",
      inputSchema: {
        // Schema definition for your tool
      }
    }
  ];
}

Implement the handler function for the tool:

export async function handleYourNewTool(
  args: Record<string, any>,
  storage: StorageInterface
): Promise<(TextContent | ImageContent | EmbeddedResource)[]> {
  // Implement your tool logic here
  return [{ type: "text", text: "Your tool response" }];
}

Register the handler in src/server.ts by adding it to the call_tool handler:

server.call_tool(async (name: string, arguments_: any) => {
  logger.info(`Handling tool call: ${name}`);
  logger.debug(`Tool arguments: ${JSON.stringify(arguments_)}`);

  if (!arguments_ || typeof arguments_ !== 'object') {
    logger.error("Invalid arguments: not an object");
    throw new InvalidParamsError("Invalid arguments");
  }

  try {
    if (name === "quip_read_spreadsheet") {
      if (!storageInstance) {
        throw new StorageError("Storage not initialized");
      }
      return await handleQuipReadSpreadsheet(arguments_, storageInstance, options.mock);
    } else if (name === "your_new_tool") {
      return await handleYourNewTool(arguments_, storageInstance);
    } else {
      logger.error(`Unknown tool: ${name}`);
      throw new MethodNotFoundError(`Unknown tool: ${name}`);
    }
  } catch (error) {
    if (error instanceof QuipMCPError) {
      throw error;
    }
    const errorMessage = error instanceof Error ? error.message : String(error);
    logger.error(`Tool call failed: ${errorMessage}`);
    throw new QuipApiError(`Tool call failed: ${errorMessage}`);
  }
});

Contributing

Contributions are welcome! Here's how you can contribute to the project:

Fork the repository
Create a new branch (git checkout -b feature/your-feature-name)
Make your changes
Run tests to ensure everything works (npm test)
Commit your changes (git commit -m 'Add some feature')
Push to the branch (git push origin feature/your-feature-name)
Open a Pull Request

Please make sure your code follows the project's coding standards and includes appropriate tests.

License

MIT License

Name		Name	Last commit message	Last commit date
Latest commit History 14 Commits
.clinerules		.clinerules
.github/workflows		.github/workflows
example-client		example-client
infrastructure		infrastructure
memory-bank		memory-bank
src		src
tests/unit		tests/unit
.env.example		.env.example
.eslintignore		.eslintignore
.eslintrc.js		.eslintrc.js
.gitignore		.gitignore
LICENSE		LICENSE
README.md		README.md
jest.config.js		jest.config.js
package-lock.json		package-lock.json
package.json		package.json
tsconfig.json		tsconfig.json
tsconfig.test.json		tsconfig.test.json

License

zxkane/quip-mcp-server-typescript

Folders and files

Latest commit

History

Repository files navigation

Quip MCP Server (TypeScript)

Table of Contents

Features

Installation

Using npm

From Source

Environment Variables

Usage

Running the Server

Transport Documentation

Configure for Claude.app

Command Line Arguments

Deploy to AWS Lambda + API Gateway

Available Tools

quip_read_spreadsheet

Resource URIs

Default Protocol (quip://)

File Protocol (with --file-protocol option)

S3 Protocol (when using S3 storage)

Presigned S3 URLs (when using S3 storage with USE_PRESIGNED_URLS=true)

How It Works

Error Handling

Mock Mode

Structured Logging

Authentication

Caching

Storage Options

Local Storage

S3 Storage

Health Check Endpoint

Cloud Deployment

AWS Lambda + API Gateway

Development

Project Structure

Setting Up a Development Environment

Scripts

Running Tests

Debugging

Adding New Tools

Contributing

License

About

Topics

Resources

License

Stars

Watchers

Forks

Releases 1

Contributors 2

Languages
